Steering Gear Outer Ball Head 45460-09290 for Toyota Avalon
4546009290 - Chassis parts
Price Details
Dealer Price ≠ Your Price
Official dealer price is only a benchmark. Your LongTop quote is significantly lower.
| Brand | Longtop Supply Quote | Action |
|---|---|---|
| FAW Toyota | $9.55 | Check Better Price |
| GAC Toyota | $9.55 | Check Better Price |
| Imported Toyota | $9.72 | Check Better Price |
Compatible Models
Vehicle models currently mapped to this OE part.
| # | Brand | Model |
|---|---|---|
| 1 | Toyota | Toyota - General area - AVALON (CHINA) - 201903 - AXXA50,AXXH50,MXXA50 |
| 2 | Toyota | Toyota - General area - Asian Dragon: AVALON (CHINA) - 201903 - AXXA50,AXXH5#,MXXA50,MXXH50 |
| 3 | Toyota | Toyota - General area - Asian Dragon: AVALON (CHINA) - 201903 - AXXA50,AXXH50,MXXA50 |
| 4 | Toyota | Toyota - General area - Camry Hybrid: CAMRY/HYBRID (CHINA) - 201712 - ASV71,AXVA70,AXVH71,MXVA71 |
| 5 | Toyota | Toyota - General area - Camry Hybrid: CAMRY/HYBRID (CHINA) - 202403 - AXVH80,MXVA80,MXVH80 |
Product Overview
The genuine Toyota steering gear outer ball head (right), OE 45460-09290, links the steering rack to the knuckle and sets the steering angle. It is used on AVALON (CHINA) and CAMRY/HYBRID (CHINA), built from 2017 to 2024. 9 cross-reference numbers apply, including SE-A411R, CE0872R and CET-221R.
Send your VIN or OE number for a wholesale quotation with worldwide export shipping.
Technical Specifications
| OE Number | 4546009290 |
| Part Name | Steering gear outer ball head (right) |
| Brand | Toyota |
| Position | Front Right Outer |
| Type | Tie Rod End |
| Mounting Length | 210 mm |
| Mounting Height | 36 mm |
| Thread | M16x1.5 RHT |
| Cone Size | 13.5 mm |
| Cone Thread | M12x1.25 mm |
| Material | Iron |
| Fitment | Toyota Camry 2017- (ASV70 ASV71 AXVA70 AXVH71 GSV70), Toyota Avalon (AXXA50 AXXH50 MXXA50) |
OE Cross-Reference
| SE-A411R | 555 |
| CE0872R | CTR |
| CET-221R | CTR |
| TA3567 | Delphi |
| 0121-ASV70RH | Febest |
| 45460-09320 | Toyota |
| 45460-80008 | Toyota |
| 45460-09280 | Toyota |
| TO-ES-17832 | MOOG |
Questions and Answers
Which Toyota and Lexus models does 45460-09290 fit?
Genuine Toyota Steering Gear Outer Ball Head (Right) 45460-09290 is used on AVALON (CHINA) and CAMRY/HYBRID (CHINA), built from 2017 to 2024.
Which OEM part numbers interchange with 45460-09290?
9 interchangeable part numbers are listed for 45460-09290, including SE-A411R (555), CE0872R (CTR), CET-221R (CTR), TA3567 (Delphi).
How can I verify that 45460-09290 is a genuine Toyota part?
Check three things: (1) the box label carries the ten-character Toyota number 45460-09290 together with the country-of-origin marking; (2) the part number is die-stamped or laser-etched into the metal itself rather than printed in ink, and it matches the box label; (3) the metal carries the supplier’s mark cast or stamped next to Toyota’s own mark, not a separate printed sticker. We can supply the commercial invoice, packing list and, on request, a Certificate of Origin for any shipment.
Where is 45460-09290 installed on the vehicle?
It is fitted in the Front Right Outer position.
How many pieces are needed for 45460-09290?
Supplied as one piece per position – check the quantity required for your application.
Is 45460-09290 the same part across different markets?
As a Toyota Genuine Parts number, 45460-09290 is the same across markets; where another catalog lists a different number for the same function, that number is the superseded one – confirm with our sales team before dispatch.
