Tire Pressure Sensor 42607-52020 for Toyota COROLLA
4260752020 - Electrical components
Price Details
Dealer Price ≠ Your Price
Official dealer price is only a benchmark. Your LongTop quote is significantly lower.
| Brand | Longtop Supply Quote | Action |
|---|---|---|
| FAW Toyota | $32.55 | Check Better Price |
| GAC Toyota | $32.55 | Check Better Price |
| Imported Toyota | $47.24 | Check Better Price |
Replacements
Alternative OE numbers related to this product.
| Brand | Original OE | Replacement OE |
|---|---|---|
| - | 4260752020 | 4260733040 |
Compatible Models
Vehicle models currently mapped to this OE part.
Show all 32 mapped vehicle models
| # | Brand | Model |
|---|---|---|
| 1 | Toyota | Toyota - General area - COROLLA/ALTIS (ASIA) - 201310 - NDE170,NZE170,ZRE17#,ZZE172 |
| 2 | Toyota | Toyota - General area - YARIS (5D) - 201310 - NCP15#,NSP15 |
| 3 | Toyota | Toyota - General area - YARIS/VIOS/LIMO (4D) - 201304 - NCP15#,NSP15 |
| 4 | Toyota | Toyota - General area - Camry Hybrid: CAMRY/HYBRID (ASIA) - 201112 - 202007 - ACV51,ASV5#,AVV50 |
| 5 | Toyota | Toyota - General area - Corolla: COROLLA/ALTIS - 201310 - NDE170,NZE170,ZRE17#,ZZE172 |
| 6 | Toyota | Toyota - General area - Senna: SIENTA (TAIWAN) - 201611 - NSP170,ZSP170 |
| 7 | Toyota | Toyota - General area - Vios: VIOS/YARIS - 202101 - NSP151 |
| 8 | Toyota | Toyota - General area - PREVIA: PREVIA/TARAGO - 200601 - 201910 - ACR50,GSR50 |
| 9 | Toyota | Toyota - General area - Prius: PRIUS C - 201112 - 202106 - NHP10 |
| 10 | Toyota | Toyota - General area - Rong Fang: RAV4 - 201212 - 201812 - ALA49,ASA4#,AVA4#,ZSA4 |
| 11 | Toyota | Toyota - General area - Yaris: YARIS - 201310 - NCP15#,NSP15 |
| 12 | Toyota | Toyota - General area - Yaris/Vios/LIMO :YARIS/VIOS/LIMO - 201304 - NCP15#,NSP15 |
| 13 | Toyota | Toyota - Europe - Prius: PRIUS /V/A(ALPHA) - 201203 - 202109 - ZVW40 |
| 14 | Toyota | Toyota - Europe - Prius: PRIUS - 201511 - ZVW5 |
| 15 | Toyota | Toyota - Europe - Prius: PRIUS - 201511 - 202211 - ZVW5 |
| 16 | Toyota | Toyota - Europe - Prius Plug-in: PRIUS PHV - 201609 - ZVW52 |
| 17 | Toyota | Toyota - Europe - Prius Plug-in: PRIUS PHV - 201609 - 202211 - ZVW52 |
| 18 | Toyota | Toyota - Europe - Rong Fang: RAV4 - 201212 - 201909 - ALA4#,ASA44,AVA4#,WWA42,ZSA4 |
| 19 | Toyota | Toyota - United States/Canada - MIRAI - 201506 - 202005 - JPD10 |
| 20 | Toyota | Toyota - United States/Canada - SCION IM/IM - 201506 - 201805 - ZRE186 |
| 21 | Toyota | Toyota - United States/Canada - Prius: PRIUS C - 201112 - 202106 - NHP10 |
| 22 | Toyota | Toyota - United States/Canada - Prius: PRIUS V - 201109 - 201811 - ZVW41 |
| 23 | Toyota | Toyota - United States/Canada - Prius: PRIUS - 201511 - ZVW5 |
| 24 | Toyota | Toyota - United States/Canada - Prius: PRIUS - 201511 - 202211 - ZVW5 |
| 25 | Toyota | Toyota - United States/Canada - Prius Plug-in: PRIUS PRIME(PHV) - 201609 - ZVW52 |
| 26 | Toyota | Toyota - United States/Canada - Prius Plug-in: PRIUS PRIME(PHV) - 201609 - 202211 - ZVW52 |
| 27 | Toyota | Toyota - United States/Canada - Rong Fang: RAV4 (JPP) - 201212 - 201810 - ASA4#,AVA44 |
| 28 | Toyota | Toyota - United States/Canada - Yaris: YARIS (JPP) - 201108 - 201407 - NCP131 |
| 29 | Toyota | Toyota - United States/Canada - Yaris: YARIS - 201310 - NCP15#,NSP15 |
| 30 | Toyota | Toyota - United States/Canada - Yaris/Vios/LIMO :YARIS/VIOS/LIMO - 201304 - NCP15#,NSP15 |
Product Overview
The genuine Toyota tire pressure sensor, OE 42607-52020, measures tyre pressure and sends it to the dashboard. It is used on COROLLA/ALTIS (ASIA), MIRAI, SCION IM/IM, YARIS (5D, JPP), YARIS/VIOS/LIMO (4D) and CAMRY/HYBRID (ASIA), built from 2006 to 2021. 3 cross-reference numbers apply, including 550-0105, 4260733040 and 4260730060.
Ask for a wholesale quotation with your VIN or OE number; we ship worldwide.
Technical Specifications
| OE Number | 4260752020 |
| Part Name | Tire Pressure Sensor |
| Brand | Toyota |
| Position | Wheel rim – valve stem (TPMS) |
| Type | Tire pressure sensor (TPMS sensor / tire pressure monitor valve sub-assembly incl. cap and valve) |
| Length | 3.4276in |
| Width | 1.0649in |
| Height | 2.5025in |
| Weight | 0.3lb |
OE Cross-Reference
| 550-0105 | Denso |
| 4260733040 | Toyota |
| 4260730060 | Toyota |
Questions and Answers
Which Toyota or Lexus vehicles is 42607-52020 used on?
42607-52020 covers COROLLA/ALTIS (ASIA), MIRAI, SCION IM/IM, YARIS (5D, JPP), YARIS/VIOS/LIMO (4D) and CAMRY/HYBRID (ASIA), with production years 2006 to 2021.
What part numbers replace 42607-52020?
Listed on this page are 3 interchangeable numbers for 42607-52020, among them 550-0105 (Denso), 4260733040 (Toyota), 4260730060 (Toyota).
What are the dimensions of 42607-52020?
Measuring 3.4276in long, 1.0649in wide, and 2.5025in high, this Toyota Tire Pressure Sensor (part number 42607-52020) is a genuine unit.
How can I verify that 42607-52020 is a genuine Toyota part?
To verify this Tire Pressure Sensor, look for the ten-character number 42607-52020 on the box label together with the country-of-origin marking, then check that the connector face shows no moulding flash and the latch closes with a crisp detent, and that the OE supplier’s mark is moulded or etched on the component next to the Toyota number (DENSO on coils and sensors). We can provide the invoice, packing list and CoO for any order.
Where is 42607-52020 installed on the vehicle?
It is fitted in the Wheel rim – valve stem (TPMS) position.
How many pieces are needed for 42607-52020?
Sold as one piece per position – check the quantity required for your application.
Is there anything I need to know before installing this part?
A few points before you fit it: Disconnect the battery negative terminal first and avoid touching the connector pins.
Is the genuine part worth it compared with an aftermarket equivalent?
What the genuine item buys you is concrete: the factory-keyed connector plugs straight into your harness with no adapters or rewiring; and the unit is calibrated to the factory signal range, so the ECU reads it without fault codes. These are the aftermarket equivalents you may also see quoted.
