Steering Outer Ball Joint 45470-49025 for Toyota Highlander
4547049025 - Chassis parts
Price Details
Dealer Price ≠ Your Price
Official dealer price is only a benchmark. Your LongTop quote is significantly lower.
| Brand | Longtop Supply Quote | Action |
|---|---|---|
| FAW Toyota | $21.55 | Check Better Price |
| GAC Toyota | $21.55 | Check Better Price |
| Imported Toyota | $23.49 | Check Better Price |
| Lexus | $23.75 | Check Better Price |
Compatible Models
Vehicle models currently mapped to this OE part.
Product Overview
The genuine Lexus steering outer ball joint (left), OE 45470-49025, links the steering rack to the knuckle and sets the steering angle. It fits LEXUS RX270/350/450H, LEXUS RX350/450H, HIGHLANDER (JPP) and HIGHLANDER/KLUGER, built from 2007 to 2008. 9 interchangeable part numbers are listed, including SE-T391L, CET-182 and TO-ES-15101.
Send your OE number or VIN for a wholesale quotation and worldwide shipping.
Technical Specifications
| OE Number | 4547049025 |
| Part Name | Steering outer ball joint (left) |
| Brand | Toyota |
| Position | Front Left Outer |
| Type | Outer Tie Rod End (Steering Ball Joint) |
| Install Length | 195 mm |
| Overall Length | 214 mm |
| Total Height | 82.2 mm |
| Install Height | 35 mm |
| Thread Size | M16x1.5 RHT |
| Taper Diameter | 13.65 mm |
| Taper End Thread | M12x1.25 |
| Taper Ratio | 1:6 |
| Material | Steel |
| Fitment | Toyota Highlander (2008-2019 ASU40 ASU50 GSU40 GSU45 GSU55 GVU48 1AR-FE 2GR-FE), Lexus RX270/RX350/RX450h (2008-2015 AGL10 GGL15 GYL10 GYL15) |
OE Cross-Reference
| SE-T391L | 555 |
| CET-182 | CTR |
| TO-ES-15101 | MOOG |
| ADT387205 | BLUE PRINT |
| TA5400 | DELPHI |
| 43225 | FEBI BILSTEIN |
| JTE7771 | TRW |
| 0121-GSU40LH | FEBEST |
| 59111 | SPIDAN |
Questions and Answers
Which Toyota and Lexus models does 45470-49025 fit?
Genuine Lexus Steering Outer Ball Joint (Left) 45470-49025 is used on LEXUS RX270/350/450H, HIGHLANDER (JPP) and HIGHLANDER/KLUGER, built from 2007 to 2008. Chassis codes include AGL10, GGL1#, GYL1#, GGL15, ASU40, GSU4#, GVU48, MHU48.
Which chassis codes does 45470-49025 cover?
Chassis codes include AGL10, GGL1#, GYL1#, GGL15, ASU40, GSU4#, GVU48, MHU48.
Which OEM part numbers interchange with 45470-49025?
9 interchangeable part numbers are listed for 45470-49025, including SE-T391L (555), CET-182 (CTR), TO-ES-15101 (MOOG), ADT387205 (BLUE PRINT).
How can I verify that 45470-49025 is a genuine Toyota part?
A genuine Steering Outer Ball Joint (Left) shows the Toyota number 45470-49025 on the box label with the country-of-origin marking. On the part itself, the metal carries the supplier’s mark cast or stamped next to Toyota’s own mark, not a separate printed sticker; and the part number is die-stamped or laser-etched into the metal itself rather than printed in ink, and it matches the box label. Documentation is available on request – commercial invoice, packing list and Certificate of Origin.
Is 45470-49025 a front or rear part?
This part is listed for the Front Left Outer position.
How many pieces are needed for 45470-49025?
Supplied as one piece per position – check the quantity required for your application.
Is the genuine part worth it compared with an aftermarket equivalent?
The genuine part earns its price in details that matter over time: the OE heat treatment and surface finish help the part resist wear, corrosion and seizing; and the part is machined to OE tolerance, so it mounts and seats without shimming or rework. These are the aftermarket equivalents you may also see quoted.
What documentation comes with an order?
Every shipment can include the commercial invoice and packing list, and on request a Certificate of Origin; the part number is die-stamped or laser-etched into the metal, so you can match it against the invoice.
