Servo Motor 87106-0N080 for Toyota Crown
871060N080 - Electrical components
Price Details
Dealer Price ≠ Your Price
Official dealer price is only a benchmark. Your LongTop quote is significantly lower.
| Brand | Longtop Supply Quote | Action |
|---|---|---|
| FAW Toyota | $25.25 | Check Better Price |
| Imported Toyota | $22.96 | Check Better Price |
Replacements
Alternative OE numbers related to this product.
| Brand | Original OE | Replacement OE |
|---|---|---|
| - | 871060N080 | 871060N030 |
Compatible Models
Vehicle models currently mapped to this OE part.
Product Overview
This is a genuine Toyota OEM servo motor (internal and external circulation), OE 87106-0N080, which drives the air conditioning compressor or the blower. It is used on CROWN (CHINA) and REIZ, built from 2009 to 2010. 2 cross-reference numbers apply, including 871060N030 and 063800-0171PLS.
Ask for a wholesale quotation with your VIN or OE number; we ship worldwide.
Technical Specifications
| OE Number | 871060N080 |
| Part Name | servo motor (internal and external circulation) |
| Brand | Toyota |
| Position | HVAC air intake assembly (internal/external circulation door) |
| Type | Servo motor (internal and external circulation) |
| Length | 88mm |
| Width | 72mm |
| Height | 44mm |
| Weight | 84g |
OE Cross-Reference
| 871060N030 | Toyota |
| 063800-0171PLS | Denso |
Questions and Answers
Which Toyota and Lexus models does 87106-0N080 fit?
Genuine Toyota Servo Motor (Internal And External Circulation) 87106-0N080 is used on CROWN (CHINA) and REIZ, built from 2009 to 2010. Chassis codes include GRS20#, UZS200, GRX13#.
Which chassis codes does 87106-0N080 cover?
Chassis codes include GRS20#, UZS200, GRX13#.
Which OEM part numbers interchange with 87106-0N080?
2 interchangeable part numbers are listed for 87106-0N080, including 871060N030 (Toyota), 063800-0171PLS (Denso).
What are the dimensions of 87106-0N080?
Genuine Toyota Servo Motor (Internal And External Circulation) 87106-0N080 measures 88mm long, 72mm wide, and 44mm high.
How can I verify that 87106-0N080 is a genuine Toyota part?
To verify this Servo Motor (Internal And External Circulation), look for the ten-character number 87106-0N080 on the box label together with the country-of-origin marking, then check that the connector face shows no moulding flash and the latch closes with a crisp detent, and that the OE supplier’s mark is moulded or etched on the component next to the Toyota number (DENSO on coils and sensors). We can provide the invoice, packing list and CoO for any order.
Where is 87106-0N080 installed on the vehicle?
It is fitted in the HVAC air intake assembly (internal/external circulation door) position.
How many pieces are needed for 87106-0N080?
Supplied as one piece per position – check the quantity required for your application.
Is there anything I need to know before installing this part?
Yes. Disconnect the battery negative terminal first and avoid touching the connector pins.
FIND THE RIGHT OE PART
Precision in Every Part. Excellence in Every Price.
Typically replies within 10 mins
Recommended Products
Blower Motor Assembly 16363-47050 for Toyota ALPHARD
