No. 1 Traction Arm Bushing Subassembly 48702-60120 for Toyota Land Cruiser
4870260120 - Chassis parts
Compatible Models
Vehicle models currently mapped to this OE part.
Product Overview
The genuine Toyota no. 1 traction arm bushing subassembly, OE 48702-60120, pivots the control arm while damping road noise and vibration. It is used on LAND CRUISER, built from 2007 to 2014. 5 cross-reference numbers apply, including TAB-207, VKDS831026 and 48702-60060.
Ask for a wholesale quotation with your VIN or OE number; we ship worldwide.
Technical Specifications
| OE Number | 4870260120 |
| Part Name | No. 1 traction arm bushing subassembly |
| Brand | Toyota |
| Position | Rear |
| Type | Rear control arm bushing sub-assembly (traction arm bush) |
| Fitment | Toyota Land Cruiser 70 Series 2007- (FZJ78 FZJ79 GRJ71 GRJ76 GRJ78 GRJ79 HZJ71 HZJ76 HZJ78 HZJ79 VDJ76 VDJ78 VDJ79 GDJ71 GDJ76 GDJ78 GDJ79 1FZ-FE 1GR-FE 1HZ 1VD-FTV 1GD-FTV) |
| Material | Rubber and Steel |
| Weight | 0.42 kg |
OE Cross-Reference
| TAB-207 | Febest |
| VKDS 831026 | SKF |
| 48702-60060 | Toyota |
| 48702-60050 | Toyota |
| 48702-60011 | Toyota |
Questions and Answers
Which Toyota or Lexus models and years does 48702-60120 cover?
48702-60120 fits LAND CRUISER, built from 2007 to 2014. Chassis codes include FZJ7#, GDJ7#, GDJL7#, GRJ7#, HZJ7#, VDJ7#, VDJL7#.
Which chassis codes does 48702-60120 cover?
Chassis codes include FZJ7#, GDJ7#, GDJL7#, GRJ7#, HZJ7#, VDJ7#, VDJL7#.
What is the cross-reference for 48702-60120?
5 numbers interchange with 48702-60120, including TAB-207 (Febest), VKDS 831026 (SKF), 48702-60060 (Toyota), 48702-60050 (Toyota).
Where is 48702-60120 installed on the vehicle?
It is fitted in the Rear position.
How many pieces are needed for 48702-60120?
You get one piece per position – check the quantity required for your application.
Is there anything I need to know before installing this part?
Worth knowing first: Torque the fasteners with the suspension at ride height and have the alignment checked afterwards.
Is the genuine part worth it compared with an aftermarket equivalent?
The genuine part differs in ways that show up in service: the number is confirmed against the official Toyota catalog, so the application is exactly right for your chassis, and the part is verified against the OE number before dispatch, so you receive exactly what your chassis requires. These are the aftermarket equivalents you may also see quoted.
